Waterproof Fiber Optic Dome Enclosure 144 Core Outdoor Joint Box Ip68

Name: Waterproof Fiber Optic Dome Enclosure 144 Core Outdoor Joint Box Ip68
Brand: Twilight Optic
Price: 1 USD

China Waterproof Fiber Optic Dome Enclosure 144 Core Outdoor Joint Box Ip68 wholesale

Brand Name : Twilight Optic

Model Number : TW-GJSM11/RS-AS

Place of Origin : China

MOQ : Negotiable

Price : Negotiable

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 10000 Piece/Pieces per Week

Delivery Time : 10-15 work days

Packaging Details : Standard export carton packing.

product name : splice enclosure 144 cores

Dimension(mm) : 320mm x Φ230mm

Number of Splice Trays : 1~6ieces(24F/tray)

Number of Inlet/Outlet Ports : 11 Pieces(1 x Oval + 10 x Round)

Diameter of Fiber Cable : Φ7mm~Φ12mm

Max capacity : 144 Core

Contact Now

144 Core Fiber Optic Enclosure Dome Closure Outdoor Mini Fiber Joint Box Waterproof Ip68

Product Description

A type of dome closure series, used for direct connection during optical fiber transmission process, and provides joint connection protection, with 10 small round cable holes and 1 large cable hole; heat sealing with heat shrinkable casing; can be used for overhead, pole, wall and buried installations. With good sealing performance, the simple installation and wide application range are the best choice for optical fiber connection.

Application

1. Aerial cable installation
2. Pole mounted installation
3. Wall mounted installation
4. Man hole and hand hole installation
5. FTTH access laver

Model	TW-GJSM11/RS-AS
Type	Dome type
Sealing Structure	Heat shrinkable
Number of Inlet/Outlet ports	11 ports
Cable Diameter	7-12mm
Maximum Capacity	144 Cores
Capacity per Splice Tray	24 Cores
Quantity of Splice Tray	6pcs
Body Material	PC
Sealing Material	Thermoplastic rubber
Assembling method	Aerial, direct buried, pipelined, wall mounting, manhole
Dimension	320(H)×230(D)mm
Net Weight	3.1KG
Temperature	-40℃~65℃
